3D Layered Card is a React component that stacks multiple content layers with spring-based depth, driven by pointer tracking. Each layer tilts, shifts, and scales at a slightly different rate as the cursor moves across the card, and the layers fan out on hover. Built with Framer Motion and Tailwind CSS. Works well for product showcases, feature callouts, and portfolio pieces.
Installation
Usage
import ThreeDLayeredCard from "@/components/ui/3d-layered-card";Basic Usage
<ThreeDLayeredCard
logo="/assets/logos/nyx-logo.webp"
mainImage="/character.png"
title="Interactive Card"
>
<p>Hover to see the magic!</p>
</ThreeDLayeredCard>Custom Styling
<ThreeDLayeredCard
logo="/assets/logos/nyx-logo.webp"
mainImage="/character.png"
title="Custom Card"
width={320}
height={{ collapsed: 140, expanded: 350 }}
logoSize={80}
backgroundColor="bg-gradient-to-b from-purple-500 to-blue-600"
textColor="white"
glowColor="rgba(168, 85, 247, 0.2)"
glowGradient="#a855f7"
shineIntensity={0.5}
>
<div className="space-y-2">
<h3 className="text-lg font-semibold">Custom Title</h3>
<p className="text-sm opacity-90">Custom description content</p>
</div>
</ThreeDLayeredCard>Props
| Prop | Type | Default | Description |
|---|---|---|---|
logo | string | Required | Path to the logo image. |
mainImage | string | Required | Path to the main character/image displayed on hover. |
title | string | undefined | Title text displayed in collapsed state. |
children | React.ReactNode | undefined | Content displayed in expanded state on hover. |
className | string | undefined | Additional CSS classes to apply to the container. |
width | number | string | 288 | Width of the card in pixels or CSS units. |
height | object | { collapsed: 130, expanded: 300 } | Height configuration for collapsed and expanded states. |
logoSize | number | 64 | Size of the logo in pixels. |
logoPosition | object | { expanded: 15 } | Logo position from top when expanded (in pixels). |
shineIntensity | number | 0.3 | Intensity of the shine effect (0-1). |
backgroundColor | string | "bg-gradient-to-b from-[#FF9901] via-[#DF911A] to-[#724f13]" | Background gradient classes or CSS. |
borderColor | string | undefined | Border color (requires borderWidth). |
borderWidth | string | "0" | Border width CSS value. |
textColor | string | "white" | Text color for title and content. |
glowColor | string | "rgba(255, 165, 0, 0.1)" | Glow color for hover effects. |
glowGradient | string | "#fde047" | Gradient color for the character glow effect. |
titlePosition | number | 90 | Fixed title position from top in collapsed state (in pixels). |
